The BSD-200W vehicle blind spot monitoring camera launched by Xiamen Lans Communication Co., Ltd. is an advanced visual device specifically designed for vehicle safety. It features a 2-megapixel high-definition sensor combined with a 2.7mm wide-angle lens, capable of accurately capturing real-time images of the road in the blind spots on both sides of the vehicle, effectively eliminating driving blind spots and enhancing driving safety. The product supports infrared night vision, ensuring clear imaging even in low-light conditions, to maintain all-weather monitoring effectiveness. The sturdy design of the metal and plastic housing balances durability and lightweight requirements, making it suitable for safety upgrades on various commercial vehicles and special-purpose vehicles.
High-definition blind spot monitoring, eliminating potential safety hazards
BSD-200W equipped with a 2.0 megapixel CMOS sensor, paired with a 2.7mm ultra-wide-angle lens, can cover the blind spots on both sides of the vehicle, transmitting high-definition images in real-time to the cabin display screen. Drivers can monitor the side road conditions without turning their heads, effectively preventing collision accidents during lane changes and turns, especially suitable for large buses, trucks, and construction vehicles where visibility is limited.
2. Infrared night vision enhancement, reliable operation in all weather conditions
The product is equipped with an infrared lighting module, supporting black and white imaging mode in low-light environments. When the ambient light is below 10Lux, the infrared function is automatically activated to ensure clear recognition of pedestrians, obstacles, and vehicles in night or tunnel scenarios, significantly enhancing driving safety at night.
3. Industrial-grade protective design, suitable for harsh environments
The housing is made of a composite structure of metal and high-strength plastic, featuring IP67 dust and water resistance, capable of withstanding rain, sand, and high temperature and humidity environments. The internal circuit board undergoes three protective treatments (anti-moisture, anti-salt mist, anti-mold), ensuring stable operation at extreme temperatures from -30℃ to +70℃, meeting the long-term outdoor use requirements.
4. Quick installation, strong compatibility
Equipped with a 4-core aviation-grade head connector, supporting coaxial transmission of video signals and power, simplifying the wiring process. Standard mounting holes for bracket installation are provided, compatible with various vehicle installation positions. It is compatible with the mainstream BSD blind spot monitoring systems on the market, and upgrading and改造 do not require additional adapter equipment.
| Basic Parameters | |
|---|---|
| Brand | Lance Communication |
| Product Model | BSD-200W |
| Place of Origin | China |
| Resolution | 2.0 Megapixels (1920×1080) |
| Sensor Type | 1/2.7-inch CMOS |
| Minimum illuminance | 0.01Lux (color mode) / 0Lux (infrared activation) |
| Infrared Distance | 10-15 meters (depending on environmental reflectivity) |
| Optical Parameters | |
| Focal Length | 2.7mm fixed focal length |
| Aperture | F2.0 |
| Horizontal field of view | 120° |
| Vertical field of view | 80° |
| Interface and power supply | |
| Video Interface | 4-core aviation connector head (supports AHD/TVI/CVI analog signals) |
| Power Input | DC12V±10% |
| Power Consumption | ≤3W |
| Structural parameters | |
| Shell Material | Aluminum alloy front cover + ABS plastic backshell |
| Protection grade | IP67 |
| Size | Φ82mm×65mm (excluding bracket) |
| Weight | Approx. 280g |
| Environmental Parameters | |
| Operating Temperature | -30℃ to +70℃ |
| Storage Temperature | -40℃ to +85℃ |
| Humidity range | 0%-95%RH (non-condensing) |
Commercial vehicle safety upgrade
Side blind area monitoring for large vehicles such as passenger buses, trucks, and trailers, helping drivers to observe the road conditions in the side and rear in real-time during lane changes, turns, and reversing, reducing accidents caused by blind spots.
2. Special Vehicle Operations Support
Enhance side visibility for special vehicles such as engineering, sanitation, and fire trucks, to prevent collisions with pedestrians and obstacles during operations on narrow roads or in complex environments, thereby improving operational safety.
3. Intelligent fleet management
Integrable into fleet management systems, serving as part of the ADAS driving assistance component, it combines real-time video transmission with collision warning algorithms to provide blind spot monitoring data support for fleets, optimizing driving behavior management.
4. Customized needs in the改装 market
Meet the blind spot monitoring modification needs for civilian vehicles such as SUVs and RVs, achieving enhanced side vision with simple installation to improve outdoor driving experience and safety.
Q1: Does BSD-200W support digital signal output?
A: This product defaults to outputting AHD/TVI/CVI analog signals. For digital signals (such as HDMI or network output), a separate encoder is required for conversion, or you can choose our BSD camera with network support that is compatible with the ONVIF protocol.
Q2: Will the infrared function interfere with normal imaging during the day?
A: No. The infrared light补光灯 is equipped with a photosensitive sensor, which automatically turns on only when the ambient light level is below the threshold and turns off automatically during daylight to avoid affecting the color image.
Q3: How to adjust the camera angle after installation?
A: The product features a fixed focal length design, which requires adjustment of the horizontal and pitch angles through a bracket during installation (it is recommended that the horizontal field of view covers a range of 3 meters on the vehicle's side). For electric adjustment capabilities, you may choose our company's PTZ pan-tilt-zoom camera series.
Q4: Can multiple cameras share the same power supply?
A: Sure. The 4-core aviation interface supports power parallel connection, but ensure the total power consumption does not exceed the power adapter's load capacity (e.g., a total power consumption of about 12W for 4 units of BSD-200W, it is recommended to use a DC12V/2A or higher power supply).
Q5: How long is the product warranty period? How can it be repaired?
A: Offer 2-year warranty service (excluding man-made damage). During the warranty period, if any fault occurs, please contact the local dealer or our after-sales center for factory repair or replacement service.
